All Patriot Products Ballistic Rubber Panels and Blocks contain maximum ATH fire suppressant properties that reduce the risk of fire from isolated exposure to incidental tracer rounds. The panel itself acts as a self extinguishing water release item.
The production costs of cold pressed rubber binder products are lower than those of vulcanized product as it is inferior. However, when the longevity of the product in ballistic applications is considered including service life, maintenance, replacement parts, and disposal costs the overall cost life of the range will undoubtedly be much lower when vulcanized rubber is used and less expensive overall…a best value
product.
Patriot ballistic blocks have superior strength, elasticity, and durability, with a tensile strength of 950-1150psi. Ultimate elongation: 210-300%, 100% modulus: 350-400psi, coefficient of friction: 1.2-1.25 static. UV exposure, ATSM D 925-88(00) 72 has ten inches below 275W RS UV bulb: tensile strength 5.9 % change, elongation 6.7% change.
| Part # | Description | Dimensions (L x W x H) | Weight (LBS) |
|---|---|---|---|
| PAR-2424 | Ballistic Rubber Panel (Flip-lock) | 24″ x 24″ x 2″ | 48 |
| PAR-91224 | Ballistic Rubber Block | 24″ x 9″ x 12″ | 105 |
| EPR-91224 | Special EPR Rubber Block | 24″ x 9″ x 12″ | 115 |
